D51K 1000 Vertical Ring Rolling Machine Design CNC Ring Rolling Machinery

D51K 1000 CNC Vertical Ring Rolling Machine Energy And Material Saving High Precision Ring

The Duolek D51K CNC vertical ring rolling machine is a high-precision and high-efficiency CNC machine tool suitable for processing various types of ring workpieces, such as wheel rims, wheels, gears, etc.

Performance advantages:

• Automated operation: D51K fully automatic CNC ring rolling machine, equipped with loading and unloading robotic arms and robots, achieving unmanned operation and improving production efficiency. During the rolling process, the robots collaborate with the machine to maintain smooth operation.  After processing, the unloading arms promptly remove the finished rings.This setup enables seamless unmanned operation, minimizing production disruptions and maximizing efficiency by running continuously.
• Precision control: D51K fully automatic CNC ring rolling machine, driven by servo motor and PLC control system, achieves precise feed motion control and increases the stability of ring processing. Whether manufacturing small scale, high precision rings for the electronics industry or large - sized rings for heavy machinery, the D51K ensures reliable and accurate production, meeting the strictest quality standards.
• High precision machining: D51K fully automatic CNC ring rolling machine adopts digital to analog conversion module and encoder interface control to achieve high-precision machining and ensure the dimensional and shape accuracy requirements of the ring.
• Structural optimization: D51K fully automatic CNC ring rolling machine, with a long slide rail surface, rectangular cross-section, high rail accuracy, and long service life.
• Reliable sealing: D51K fully automatic CNC ring rolling machine, cylinder adopts polyurethane YX sealing ring, reliable sealing and wear-resistant.
• Easy to operate: The D51K fully automatic CNC ring rolling machine adopts a servo driven precision rolling mechanism, which is easy to operate, stable in operation, and has a wide adjustable range.
• Compact structure: D51K fully automatic CNC ring rolling machine, with a standard reducer and Y-shaped motor placed on the same base for easy installation. The muffler releases compressed air to eliminate noise pollution.
• High axial positioning accuracy: D51K fully automatic CNC ring rolling machine, the rolling gear is fixed by expanding the ring, simplifying the roller processing and improving the axial positioning accuracy.
• Easy to replace: The end of the lower support shaft is equipped with a square hole, and the connection between the rolling mill and the lower support shaft is reliable, making replacement convenient, reducing non production time consumption, and improving production efficiency.

Full service escort: providing comprehensive and thoughtful services from equipment selection consultation, personalized customization, to regular maintenance after equipment delivery. Establish customer exclusive files, track equipment usage, provide timely technical upgrade and optimization suggestions, and ensure that customer equipment is always in optimal operating condition.

If needed, please feel free to contact us at any time!

▶ Technical Parameters:

Note:

K (H): The main transmission of the machine adopts a hydraulic device.

K (P): The main transmission of the machine adopts a pneumatic devic.

▶ Display of Rolled Ring Shaped Products:

▶ Why choose us?

• Export Experience (Global Trade)

Since its establishment in 2002, Condor Heavy Industries has successfully operated its equipment in more than 20 countries and has dealers involved.According to Chinese export customs data, Duolek's related equipment ranks among the top ten in the industry, which means reliable quality and price.

• Customize on demand

With 21 years of manufacturing and export experience, Duolek supports the design and customization of equipment on demand, provides equipment configuration details and parameter guidance, and guarantees subsequent production quality and equipment adjustment. Here, you can get professional advice for your needs.

▶ Customer factory inspection communication:

▶ Our Clients Say

  ▶ Duolek Factory Common inquiry

Q:What information we need customers to provide?

A:Duolek has R&D Center to focus on the study for new product. We can design and make the change as customer’s requirements. We keep an opened mind to service our customers.

Q:What’s your quality control system?

A:We operate ISO9001 Quality Management System. We control our products quality by our workshop processes: Materials incoming inspection, Machining process control, finished testing and Inspection before packing. Each step has inspector and the testing results will be recorded for checking.

Q:What kind of payment terms do you accept?

A:We prefer T/T through bank. 30% when order is confirmed and 70% before shipment. L/C is also acceptable for amount over 200,000USD.

Q:What is your warranty policy?

A:All our products are warranted for one full year from date of delivery against defects in materials and workmanship.This warranty does not cover parts that are worn out through the course of normal operation
