Customization Horizontal Ring Rolling Machine Large Seamless Ring Components Energy Conservation

MOQ: 1 Set
Price: 25000 - 493000 USD Per Set
Standard Packaging: After Being Wrapped With Stretch Film, It Is Shipped Unpacked In The Container.
Delivery Period: 45-75 Working Days
Payment Method: L/C,T/T
Details Information
Product Description
Detail Information
Brand Name
DORCO
Model Number
D53KT
Cooling System:
Water Cooling
Security Features:
Emergency Stop Button, Safety Protection Device, Overload Protection
Application:
Large Size, High-precision Ring Processing
Warranty:
1 Year
Equipment Size:
Customized According To The Model
Advantage:
Dual Directional Composite Rolling Function
Highlight:

Seamless Horizontal Ring Rolling Machine

,

Customization Horizontal Ring Rolling Machine

,

Horizontal Ring Components Rolling Machine

Product Description
Customization Horizontal Ring Rolling Machine Large Seamless Ring Components Energy Conservation
Product Attributes
Attribute Value
Cooling System Water Cooling
Security features Emergency Stop Button, Safety Protection Device, Overload Protection
Application Large Size, High-precision Ring Processing
Warranty 1 Year
Equipment size Customized According To The Model
Advantage Dual Directional Composite Rolling Function
Product Description

The horizontal ring rolling mill is an advanced solution for manufacturing large-sized and high-precision ring components. This key equipment is designed for producing high-quality ring forgings in industries such as automotive, aerospace, and energy.

Core Advantages
Flexible customization to meet unique production requirements and achieve optimal performance
Multi-parameter real-time monitoring of rolling pressure, speed, temperature, and position
High-precision collaborative rolling of radial and axial directions for superior ring quality
Intelligent process adaptation with dynamic parameter optimization
Multi-material compatibility including carbon steel, stainless steel, and titanium alloy
Non-standard customization support with professional technical assistance
Comprehensive data traceability and management system
Technical Parameters (DRC-D53KT Series)
Model 800 1200 1600 2000 2500 3500 4000
Nominal outer diameter (mm) 800 1200 1600 2000 2500 3500 4000
Rolling diameter range (mm) 300-800 300-1200 400-1600 400-2000 500-2500 700-3500 800-4000
Rolling height (mm) 60-250 60-300 60-350 60-400 80-500 80-600 80-700
Radial rolling force (KN) 1000 1250 1600 2000 2500 3000 3000
Axial rolling force (KN) 800 1000 1250 1600 2000 2500 2500
Linear rolling speed (m/s) 1.3 1.3 1.3 1.3 1.3 1.3 1.3
Radial motor power (Kw) 160 250 280 355 2*280 2*315 2*355
Axial motor power (Kw) 2*75 2*110 2*160 2*220 2*280 2*315 2*355
Overall dimensions (mm) 8580×2280×3500 9050×2450×3550 11050×2580×3680 13080×3080×3880 14080×3580×4380 17080×3880×4580 18100×4250×4650
Model 5000 6000 6300 7000 8000 9000 10000
Nominal outer diameter (mm) 5000 6000 6300 7000 8000 9000 10000
Rolling diameter range (mm) 800-5000 800-6000 1000-6300 1000-8000 1100-8000 1100-9000 1200-10000
Rolling height (mm) 80-800 80-800 100-1000 100-1200 100-1600 110-1600 120-1650
