High Precision Horizontal Ring Rolling Machine for Large Seamless Rings

MOQ: 1 Set
Price: 25000 - 493000 USD Per Set
Standard Packaging: After Being Wrapped With Stretch Film, It Is Shipped Unpacked In The Container.
Delivery Period: 45-75 Working Days
Payment Method: L/C,T/T
Details Information
Product Description
Detail Information
Brand Name
DORCO
Model Number
D53KT
Features:
High Precision, High Efficiency, Easy Operation
Application:
Machinery, Automotive, Aerospace, Energy And Other Fields
Safety Features:
Emergency Stop Button, Safety Protection Device, Overload Protection
Machine Main Transmission:
Hydraulic Or Pneumatic Device
Cooling System:
Water
Overall Dimensions:
Different According To The Model
Highlight:

high precision horizontal ring rolling machine

,

large seamless ring rolling machine

,

horizontal ring rolling machine for rings

Product Description
High Precision Horizontal Ring Rolling Machine For Large Seamless Ring Components
Key Attributes
Attribute Value
Application Machinery, Automotive, Aerospace, Energy And Other Fields
Features High Precision, High Efficiency, Easy Operation
Safety features Emergency Stop Button, Safety Protection Device, Overload Protection
Machine main transmission Hydraulic Or Pneumatic Device
Cooling system Water
Overall dimensions Different According To The Model
Product Overview

The D53KT series CNC radial axis rolling machine is one of DORCO Heavy Industries' mature products, designed specifically for rolling large ring parts. It combines radial and axial rolling capabilities to ensure dimensional accuracy and quality for large seamless ring components.

Key Features
  • Safety Systems: Emergency stop button, safety protection device, and overload protection for secure operation
  • Flexible Power Options: Configurable with hydraulic or pneumatic main transmission systems
  • Efficient Cooling: Water-based cooling system maintains optimal operating temperatures
  • Versatile Applications: Suitable for machinery components, automotive parts, aerospace structures, and energy equipment
  • Custom Sizing: Various dimensions available to match specific production requirements
Technical Specifications
DRC-D53KT Model 800 1200 1600 2000 2500 3500 4000
Nominal outer diameter (mm) 800 1200 1600 2000 2500 3500 4000
Rolling diameter range (mm) 300-800 300-1200 400-1600 400-2000 500-2500 700-3500 800-4000
Ring height (mm) 60-250 60-300 60-350 60-400 80-500 80-600 80-700
Radial rolling force (KN) 1000 1250 1600 2000 2500 3000 3000
Axial rolling force (KN) 800 1000 1250 1600 2000 2500 2500
Linear rolling speed (m/s) 1.3 1.3 1.3 1.3 1.3 1.3 1.3
DRC-D53KT Model 5000 6000 6300 7000 8000 9000 10000
Nominal outer diameter (mm) 5000 6000 6300 7000 8000 9000 10000
Rolling diameter range (mm) 800-5000 800-6000 1000-6300 1000-8000 1100-8000 1100-9000 1200-10000
Ring height (mm) 80-800 80-800 100-1000 100-1200 100-1600 110-1600 120-1650
Radial rolling force (KN) 3600 4000 5000 6300 8000 8000 10000
Axial rolling force (KN) 3000 3150 4000 5000 6300 6300 8000
Material Applications

Processes various specifications of carbon steel, stainless steel, titanium alloy and other materials for ring components, meeting diverse needs in high-end fields including wind power and aerospace applications.

High Precision Horizontal Ring Rolling Machine for Large Seamless Rings 0
High Precision Horizontal Ring Rolling Machine for Large Seamless Rings 1
High Precision Horizontal Ring Rolling Machine for Large Seamless Rings 2
