D53KT-6300 Horizontal Ring Rolling Machine 1000-6300mm Diameter Range

MOQ: 1 Set
Price: 25000 - 493000 USD Per Set
Standard Packaging: After Being Wrapped With Stretch Film, It Is Shipped Unpacked In The Container.
Delivery Period: 45-75 Working Days
Payment Method: L/C,T/T
Details Information
Product Description
Detail Information
Place of Origin
China
Brand Name
Duolek
Model Number
D53KF
Model:
D53KT - 6300
Nominal Outer Diameter Of Grinding Ring:
6300 Mm
Range Of Outer Diameter Of Rolling Ring:
1000 - 6300
Equipment Size:
Customized According To The Model
Cooling System:
Water Cooling
Security Features:
Emergency Stop Button, Safety Protection Device, Overload Protection
Highlight:

Horizontal Ring Rolling Machine 6300mm diameter

,

D53KT-6300 Ring Rolling Machine

,

Horizontal Ring Roller 1000-6300mm range

Product Description
Multi Station Horizontal Ring Rolling Machine Double Directional Composite Rolling Flexible Production
The D53KT series CNC radial axial ring rolling machine is a mature equipment launched by Duolek Heavy Industry, specifically designed for precision rolling of large ring components. This device has the function of radial and axial composite rolling, which can significantly improve the dimensional accuracy and overall quality of ring forming.
Technical Specifications
Model DRC-D53KT (800-4000mm)
Parameter 800 1200 1600 2000 2500 3500 4000
Nominal outer diameter of grinding ring (mm) 800 1200 1600 2000 2500 3500 4000
Range of outer diameter of rolling ring (mm) 300-800 300-1200 400-1600 400-2000 500-2500 700-3500 800-4000
Ring rolling height (mm) 60-250 60-300 60-350 60-400 80-500 80-600 80-700
Radial rolling force (KN) 1000 1250 1600 2000 2500 3000 3000
Axial rolling force (KN) 800 1000 1250 1600 2000 2500 2500
Linear rolling speed (m/s) 1.3 1.3 1.3 1.3 1.3 1.3 1.3
Radial motor power (Kw) 160 250 280 355 2*280 2*315 2*355
Axial motor power (Kw) 2*75 2*110 2*160 2*220 2*280 2*315 2*355
Overall dimensions (mm) 8580*2280*3500 9050*2450*3550 11050*2580*3680 13080*3080*3880 14080*3580*4380 17080*3880*4580 18100*4250*4650
Model DRC-D53KT (5000-10000mm)
Parameter 5000 6000 6300 7000 8000 9000 10000
Nominal outer diameter of grinding ring (mm) 5000 6000 6300 7000 8000 9000 10000
Range of outer diameter of rolling ring (mm) 800-5000 800-6000 1000-6300 1000-8000 1100-8000 1100-9000 1200-10000
Ring rolling height (mm) 80-800 80-800 100-1000 100-1200 100-1600 110-1600 120-1650
Radial rolling force (KN) 3600 4000 5000 6300 8000 8000 10000
Axial rolling force (KN) 3000 3150 4000 5000 6300 6300 8000
Linear rolling speed (m/s) 0.5-1.4 0.5-1.4 0.5-1.4 0.5-1.4 0.5-1.4 0.5-1.4 0.5-1.4
Radial motor power (Kw) 2*450 2*550 2*630 2*730 2*800 2*900 2*1000
Axial motor power (Kw) 2*450 2*550 2*630 2*730 2*800 2*900 2*1000
Overall dimensions (mm) 20000*5380*4780 21100*6580*5580 24000*6880*6580 26100*7550*7250 30050*8550*8050 36050*9050*8050 40050*9550*10050
Advanced CNC System Features
  • Dual electronic handwheels for comprehensive control with user-friendly interface and efficient operation
  • Real-time monitoring of rolling pressure, speed, temperature, and position with dynamic anomaly indication
  • High-precision coordinated radial and axial control for superior roundness, wall thickness uniformity, and surface quality
  • Flexible production capability for multiple materials including carbon steel, stainless steel, and titanium alloys
  • Customization services available for non-standard requirements to enhance market competitiveness
  • Comprehensive data management with automatic production recording and historical data export
  • Multiple safety protections including overload protection, emergency stop, and collision prevention
  • Energy-saving drive control with servo motors and intelligent hydraulic systems for optimized consumption
The D53KT series ring rolling machine delivers stable and reliable performance, making it an ideal solution for large-scale ring manufacturing applications.
D53KT-6300 Horizontal Ring Rolling Machine 1000-6300mm Diameter Range 0 D53KT-6300 Horizontal Ring Rolling Machine 1000-6300mm Diameter Range 1
For more information about the D53KT series ring rolling machine, please contact us for detailed technical support and services.
