DRC-2400 Spiral Weld Pipe Mill 508-2400mm 30 Ton Capacity

MOQ: 1 Set
Price: 200000 - 1190000 USD Per Set
Standard Packaging: After Being Wrapped With Stretch Film, It Is Shipped Unpacked In The Container.
Delivery Period: 45 - 75 Working Days
Payment Method: L/C,T/T
Details Information
Product Description
Detail Information
Brand Name
Duolek
Model Number
LXHGJ
Specification(mm）:
φ 508 - φ 2400
Coil Weight (ton):
30
Model:
DRC - 2400
Auxiliary Equipment:
Steel Pipe Hydrostatic Testing Machine , Flat Head Chamfering Machine , Ultrasonic Flaw Detector , X-ray Steel Pipe Inspection
Coil Width(mm）:
1200 - 2000
Area(m2）:
24 * 200
Highlight:

Spiral Weld Pipe Mill 30 Ton Capacity

,

Spiral Weld Pipe Mill 508-2400mm

,

Spiral Weld Pipe Mill with warranty

Product Description
Multi Specification Spiral Weld Pipe Mill
Price advantage with steady operation for industrial pipe production
Product Attributes
Specification (mm) φ 508 - φ 2400
Coil weight (ton) 30
Model DRC - 2400
Auxiliary equipment Steel Pipe Hydrostatic Testing Machine, Flat Head Chamfering Machine, Ultrasonic Flaw Detector, X-ray Steel Pipe Inspection
Coil width (mm) 1200 - 2000
Area (m²) 24 * 200
Product Overview
The spiral welded pipe unit is a standard finalized unit developed and improved by Duoleke Heavy Industry, combining international molding technology with domestic manufacturing expertise. This represents the most competitive and mature unit with technical characteristics of DORCO Heavy Industry.
Key Features
  • Raw materials include strip steel coils, welding wire, and flux, all undergoing strict physical and chemical inspections
  • Strip steel connection via single or double wire submerged arc welding with active submerged arc welding for repairs
  • Comprehensive pre-forming treatment including leveling, trimming, planing, and surface cleaning
  • Precision control using electric contact pressure gauges for smooth strip steel transportation
  • External or internal control roller molding options
  • Advanced weld seam gap control for precise pipe diameter and alignment
  • High-quality welding with American Lincoln welding machines for stable results
  • Air plasma cutting for precise steel pipe separation
  • Comprehensive quality control including mechanical testing, chemical analysis, and non-destructive evaluation
Technical Specifications
Model Specification (mm) Coil Weight (ton) Coil Width (mm) Thickness (mm) Capacity (KW) Area (m²)
DRC-400 φ219-φ426 10 400-750 5-8 150 18*72
DRC-500 φ219-φ529 φ219-φ720 15 400-800 5-10 180 18*72
DRC-600 φ219-φ630 15 450-1050 6-10 190 21*72
DRC-700 φ219-φ720 15 500-1250 5-12.7 210 21*72
DRC-800 φ219-φ820 20 500-1300 6-12.7 220 24*78
DRC-1000 φ219-φ1020 20 500-1560 6-12.7 220 24*78
DRC-1400 Φ325-φ1420 25 500-1560 6-18 400 24*120
DRC-1600 Φ426-φ1620 30 1100-1600 6-20 400 24*120
DRC-1800 φ508-φ1820 30 1200-1600 8-25.4 500 24*180
DRC-2000 φ508-φ2020 30 1200-2000 8-25.4 550 24*180
DRC-2400 φ508-φ2400 30 1200-2000 8-25.4 600 24*200
DRC-3000 φ508-φ3000 30 1200-2000 8-25.4 700 24*200
Industrial Applications
The spiral welded pipe unit provides efficient forming processes and flexible adaptability for various industrial applications including:
  • High and low pressure fluid conveying pipes
  • Urban construction pile pipes
  • Industrial structural pipes
  • Power, heat, and gas pipelines
DRC-2400 Spiral Weld Pipe Mill 508-2400mm 30 Ton Capacity 0 DRC-2400 Spiral Weld Pipe Mill 508-2400mm 30 Ton Capacity 1 DRC-2400 Spiral Weld Pipe Mill 508-2400mm 30 Ton Capacity 2 DRC-2400 Spiral Weld Pipe Mill 508-2400mm 30 Ton Capacity 3
